Description
General Features:
- Area: Main Entrance (Wooden Door / Fire Rated Door)
- Easy upgrade Fire door’s lock to digital lock type
- Autolock: Yes
- Lock dimension: 25mm (D) x 72mm (L) x 360mm (H)
- Colour: Matt Black
- User Capacity: 200 fingers, 150 PINs, 200 cards, unlimited E-key
- Mortise Lockcase: 6072 / 6085 Anti Panic Function lockcase come with SUS 304 anti-friction passage latch & solid deadbolt
- Easy Installation & Set Up
- Type C USB port available for emergency power when battery life is running out
- Waterproof (IP55) on fingerprint sensor, PCBA board, motor & USB connector
- Sensitive number pad & fingerprint sensor with loud response and unlock sound
- Audit Trail available in mobile application
Main Functions:
- Mobile Application (via Bluetooth): Act as main administration; Mobile lock/unlock (e-key)
- Antipeep password (PIN): It can be customized (4-9 digits); One-time dynamic password available (suitable for AirBnb); User capacity up to 150
- Card: NFC Tag, Identity card (IC), Touch N Go card (TNG) and residential access card can be used to unlock; User capacity up to 200
- Fingerprint: Semi-conductor biometrics; High recognition rate ~98.9%; User capacity up to 200
- Mechanical keys: 2 provided; For emergency purposes
Technical Information:
- Power supply: 6V/4 x AA batteries
- 1 year batteries life
- Cycle time: 250,000 cycle
- Working Humidity: 0 – 95%
- Working Temperature: -35°C ~ 55°C
- Product Warranty: 1 years
Product Manual and Guidance:
