Description
General Features:
- Area: Grill / Aluminium Door
- Both side access control type digital lock, with remote control provided to lock/unlock from inside
- Autolock: Yes
- Lock Dimension: 23mm (D) x 39mm (L) x 310mm (H)
- Colour: SS
- User Capacity: 200 fingers, 150 PINs, 200 cards, unlimited E-key
- Mortise Lockcase: Standard 6072 come with SUS304 Anti Friction Passage Latch
- Easy installation
- Type C USB port for emergency power when battery life is running out
- Waterproof (IP55) on fingerprint sensor, PCBA board, motor & USB connector
- Suitable for grill door
- Sensitive number pad & fingerprint sensor with loud response and unlock sound
- Can check unlocked records through TTLock APP
Main Functions:
- Mobile Application (via Bluetooth) : Act as main administration; Mobile lock/unlock (e-key)
- Antipeep password (PIN): It can be customized (4-9 digits); One-time dynamic password available (suitable for AirBnb); User capacity up to 150
- Card: NFC Tag, Identity card (IC), Touch N Go card (TNG) and residential access card can be used to unlock; User capacity up to 200
- Fingerprint: Semi-conductor biometrics; High recognition rate ~98.9%; User capacity up to 200
- Mechanical keys: 2 provided; For emergency purposes
- Remote Control: Bothside access control digital lock, to lock / unlock from inside
Technical Information:
- Power supply: 6V/4 x AA batteries
- 1 year batteries life
- Cycle time: 250,000 cycle
- Working Humidity: 0 – 95%
- Working Temperature: -35°C ~ 55°C
- Product Warranty: 1 years
